技术参数/Technical data
◆使用于运动机构的速度控制
Used for controlling speed of movement
◆力值范围：20N-1000N/ Force range20N-1000N
◆支撑杆直径Φ5-Φ10mm，QPQ表面处理
Rod diameter :Φ5-Φ10mm ,QPQ plated
◆耐久寿命：3万次/Lifetime 30,000 cycles
◆使用环境温度：-40℃～+90℃
Operating temperature:-40℃～+90℃
◆外筒材质：钢，表面处理：喷塑
Outer body material：steel with power coating
◆控制阻尼的精密溢流孔隙和阀门技术
Controlled speed by damp orifice and valve in piston
◆阻尼力可通过旋转活塞杆调节
Damping force can be adjusted by rotating rod
◆双向及单向（伸出或缩进）阻尼力规格可选
Model type:Damping force on pull and push/pull/push
